1.8mm Wire Diameter 140 Meter Roll Length Pipeline Reinfored Welded Mesh For Oil Pipelines

Brand Name : H&F

Model Number : HF-250511

Certification : ISO-9001

Place of Origin : Hebei, China

MOQ : 25000 Square Meters

Price : USD4.81/M2~USD4.97/M2

Payment Terms : T/T, Western Union

Supply Ability : 88000 Square Meters per month

Delivery Time : According to order quantity

Packaging Details : 50 rolls per bundle or as customers' requirements

Product Name : Pipeline Reinfored Welded Mesh

Key word : CWC Mesh

Wire diameter : 1.8mm-2.7mm

Material : Galvanized wire

Hole Size : 25.4mm x 67mm

Line wire quantity : 6lines or 8lines,10lines

Surface treatment : hot dipped galvanized

Middle line wire pitch : 25.4 mm

Zinc coated : 70gm²~300g / m² or custom

Cross wire pitch : 67 mm or 92.4 mm

Both sides line wire pitch : 25.4 mm or 50.8 mm

Hardness range : 485N/mm2~650N/mm2

Exposed Wire Edge : ≤ 2.5 mm

Roll Diameter : 700mm~1100mm

Width : 190.5mm

Length : 140m,145m,280m etc

Load container way : In bulk or in pallet

Sample : Free sample to confirm quality

Contact Now

1.8mm Wire diameter 140Meter Roll Length Pipeline Reinfored Welded Mesh For Oil Pipelines

Pipeline Reinfored Welded Mesh Description:

Pipeline Reinforced Welded Mesh is we special design and make one kind of mesh use for offshore

Oil pipelines.It use good galvanized wire.The galvanized wire have electric galvanized wire and hot

dipped galvanized wire.Surface cover zinc coated which can make the product strong anti-rust and

anti-corrosion.Meanwhile the hole size strong welded and high tensile strength make sure use long time.

so suitable for oil pipelines project.

Pipeline Reinfored Welded Mesh specification list:

Product Name	Pipeline Reinfored Welded Mesh
Material	Hot dipped galvanized wire
Wire diameter	1.8mm-2.7mm
Hole size	25.4mm x 67mm
Surface treatment	hot dipped galvanized
Zinc coated	70gm²~300g / m² or custom
Middle line wire pitch	25.4 mm
Cross wire pitch	67 mm or 92.4 mm
Both sides line wire pitch	25.4 mm or 50.8 mm
Line wire quantity	6lines, 8lines or 10lines
Exposed Wire Edge	≤ 2.5 mm
Hardness range	485N/mm2~650N/mm2
Roll Diameter	700mm-1150mm
Width dimensions	190.5mm
Length dimensions	140m,145m,280m etc
Sample	Supply free sample to test

Pipeline Reinfored Welded Mesh export specification details:

Wire Dia.	Mesh	Width	Length
2.0mm/2.0mm	25.4mm x 67mm	190.5mm	140m, 280m
2.0mm/2.2mm	25.4mm x 67mm	190.5mm	140m, 280m
2.0mm/2.4mm	25.4mm x 67mm	190.5mm	140m, 280m
2.0mm/2.7mm	25.4mm x 67mm	190.5mm	140m, 280m

Pipeline Reinfored Welded Mesh normal export 4kinds:
