Hot Dipped Galvanized Reinfored Welded Mesh For Offshore Gas Pipeline

Brand Name : H&F

Model Number : HF-250519

Certification : ISO-9001

Place of Origin : Hebei, China

MOQ : 18000 Square Meters

Price : USD4.85/M2~USD4.96/M2

Payment Terms : T/T, Western Union

Supply Ability : 75000 Square Meters per month

Delivery Time : According to order quantity

Packaging Details : 6 rolls per bundle or as customers' requirements

Product Name : Hot dipped Galvanized Reinfored Welded Mesh

Key word : Pipeline reinforced Welded Mesh

Wire diameter : 1.8mm-2.7mm

Material : Hot dipped Galvanized wire

Line wire quantity : 6lines or 8lines,10lines

Hole Size : 25.4mm x 67mm

Surface treatment : hot dipped galvanized

Hardness range : 485N/mm2~650N/mm2

Zinc coated : 70gm²~300g / m² or custom

Middle line wire pitch : 25.4 mm

Both sides line wire pitch : 25.4 mm or 50.8 mm

Roll Diameter : 700mm~1100mm

Cross wire pitch : 67 mm or 92.4 mm

Length : 140m,145m,280m etc

Exposed Wire Edge : ≤ 2.5 mm

Width : 190.5mm

Load container way : In bulk or in pallet

Sample : Supply free sample to test

Contact Now

30Years use Hot dipped Galvanized Reinfored Welded Mesh For Offshore Gas Pipeline

Hot dipped Galvanized Reinfored Welded Mesh Description:

Hot dipped Galvanized Reinfored Welded Mesh also called Pipeline reinforced Welded Mesh.

It is welded by good quality hot dipped galvanized wire.The zinc coated range 70gm²~300g / m² or

custom.The mesh hole size in standard 25.4mm*67mm.Our machine make the hole in uniform and

same size.Make sure high tensile strength.

We can make curved lines,normal 6lines,8lines or 10lines,which in stanrad width size 190.5mm.

Surface through hot dipped galvanized,so with strong anti-rust and anti-corrosion.So suitable for

Offshore Gas Pipeline projects use.

Hot dipped Galvanized Reinfored Welded Mesh specification list:

Product Name	Hot dipped Galvanized Reinfored Welded Mesh
Material	Hot dipped galvanized wire
Wire diameter	1.8mm-2.7mm
Hole size	25.4mm x 67mm
Surface treatment	hot dipped galvanized
Zinc coated	70gm²~300g / m² or custom
Middle line wire pitch	25.4 mm
Cross wire pitch	67 mm or 92.4 mm
Both sides line wire pitch	25.4 mm or 50.8 mm
Line wire quantity	6lines, 8lines or 10lines
Exposed Wire Edge	≤ 2.5 mm
Hardness range	485N/mm2~650N/mm2
Roll Diameter	700mm-1150mm
Width dimensions	190.5mm
Length dimensions	140m,145m,280m etc
Sample	Supply free sample to test

Hot dipped Galvanized Reinfored Welded Mesh different specification for export:

Wire Dia.	Mesh	Width	Length
2.0mm/2.0mm	25.4mm x 67mm	190.5mm	140m, 280m
2.0mm/2.2mm	25.4mm x 67mm	190.5mm	140m, 280m
2.0mm/2.4mm	25.4mm x 67mm	190.5mm	140m, 280m
2.0mm/2.7mm	25.4mm x 67mm	190.5mm	140m, 280m

Hot dipped Galvanized Reinfored Welded Mesh export 4 types pipeline reinforced mesh for choice:

Hot Dipped Galvanized Reinfored Welded Mesh For Offshore Gas Pipeline

Type-01 Type-02

Hot dipped Galvanized Reinfored Welded Mesh Features:

High quality
Hole size standard
Length size in enough use
Surface smooth and clean
High tensile strength
Anti-rust
Anti-corrosion
Use long time
Easy install
Fast install
Suitable for shipping
Fast delivery time
Packing strong

Hot dipped Galvanized Reinfored Welded Mesh use details:

Hot Dipped Galvanized Reinfored Welded Mesh For Offshore Gas Pipeline

Hot dipped Galvanized Reinfored Welded Mesh use areas:

Offshore Gas pipeline
Subsea Gas & Oil Pipeline
Water and Wastewater Pipeline
Everglades Gas Pipeline
River Bottom Gas & Oil Pipeline
Chemical Processing Pipeline

Show our Hot dipped Galvanized Reinfored Welded Mesh product pictures:

Hot Dipped Galvanized Reinfored Welded Mesh For Offshore Gas Pipeline
